The ball is made of polypropylene (PP) plastic, which is composed of two hemispheres into a ball. Each hemisphere has 8-12 half sector blades according to the design requirements, and the fan blades of the two hemispheres are staggered with each other. The filler is characterized by large specific surface area and high void ratio. However, due to the large number of blades, there is shielding effect between them, which is not conducive to the distribution and wetting of the liquid; most of the liquid accumulates in the hollow column of the sphere, which hinders the smooth flow of the gas, so the resistance is large.
● the plastic polyhedral hollow ball (PP, PE, PVC, CPVC, RPP) is composed of two hemispheres into a sphere, each hemisphere is provided with 12 half fan-shaped blades, and the fan-shaped blades of the two hemispheres are staggered with each other.
● light weight, high strength, large free space, high temperature resistance, corrosion resistance, good surface hydrophilicity, small wind resistance and low power consumption. Output device with large specific surface area and suitable for various solvents.
This kind of packing is mostly used in water treatment engineering and widely used in environmental protection equipment such as chlorine remover, deaerator, carbon dioxide absorption tower, waste gas purification tower, acid mist purification tower, etc.
Product name | Plastic Polyhedron empty ball | ||||
Texture of material | PP,PE, PVC,CPVC ,RPP,and etc | ||||
Service life | >3 years | ||||
size mm | Specific surface area m2/m3 | Void % | Accum ulation number per/ m3 | Accum ulation weight Kg/m3 | Dry packing factor m-1 |
25 | 460 | 90 | 64000 | 64 | 776 |
38 | 325 | 91 | 25000 | 72.5 | 494 |
50 | 237 | 91 | 11500 | 52 | 324 |
76 | 214 | 92 | 3000 | 75 | 193 |
100 | 330 | 92 | 1500 | 56 | 155 |
perfor mance | Small void ratio, low pressure, low mass transfer unit height, high flooding point, sufficient gas-liquid contact, small specific gravity and high mass transfer efficiency | ||||
Advan tage | 1. The special structure makes its circulation large, pressure reduced and mechanical strength good. | ||||
applic ation area | It is widely used in dechlorination, oxygen removal, carbon dioxide absorption tower, waste gas purification tower, acid mist purification tower and other environmental protection equipment. | ||||
Perform ance material | PE | PP | RPP | PVC | CPVC | PVDF |
Density | 0.98 | 0.96 | 1.2 | 1.7 | 1.8 | 1.8 |
Operat tempe rature | 90 | ＞100 | ＞120 | ＞60 | ＞90 | ＞150 |
Corro sion resist ance | G | G | G | G | G | G |
comp ressive strength | ＞6.0 | ＞6.0 | ＞6.0 | ＞6.0 | ＞6.0 | ＞6.0 |
